Slim
PH-SM-06621-SL
Light Distribution:

Single Sided Lighting

Size:

1133*34*66

Beam Angle:

91.4°

Previous Page

PH-SM-06621-SL
Size: 1133*34*66
Specification
  • Input Voltage: 220-240V
  • Input Power: 30W
  • Light Source: SAMSUNG 2835 0.5W
  • Freqency Range: 50/60Hz
  • Ra: Ra>80
  • CCT: 3000/4000/6000K
  • Power Factor: 0.969
  • Lm/W: 76.4
  • Color:
  • Power Efficiency: 88.0%
  • Luminous Flux: 2200
  • Lnsulation Class: CLASS I
  • Output Voltage: DC 27-54V
  • UGR: < 19.0
  • (G.W. / N.W.): 1.9/2.4kg
  • Output Current: DC 700mA±5%
  • Beam Angle: 91.4°
  • Package Dimensions: 126*8*15.5cm
  • Lifespan: 30000H
  • Diffuser material: PMMA
Photometric Results
Aluminum specifications
Stitching method
Composite signal
Different Size
Size Input Power Lm/W Beam Angle Luminous Flux Ra
1214mm 30w 76.4 91.4° 2200 Ra>80
2420mm 60w 76.4 91.4° 4380 Ra>80
Different Power
Size Input Power Luminous Flux
L1214*W34*H66mm 20w 2090
30w 3135
40w 4180
